Send InquiryHigh Frequency Pneumatic Vibrators
Product Details:
- Supply Ability : 25 Set Per Week
Price And Quantity
- 5000.00 - 50000.00 INR/Set
- 1 Set
Trade Information
- 25 Set Per Week
- 7-10 Days
- All India
Product Description
FEATURES
| Working pressure | 6 bar |
| Air supply quality | Class 5.4.4 |
| Working temperature | -10C +60C |
| Max noise level | 103 dB(A) Silent version HFC 4001C: 90 dB(A) at 1 meter distance |
| Technology | Eccentric rotor |
| Materials | Steel and cast iron |
| Certifications | Conformity verified according to the standard document UNI EN ISO 12100 |
| Accessories | Fastening systems: CLS (Clamp for Steel form works) CRS (Cradle for Steel concrete moulds) |
Technical Specifications:
| Model | Working Pressure
| Vibration Vpm | Centr.Force Kg | Air Consump
| Noise Level dBA (a) |
| bar | vpm | kg | l/min | dB (A) | |
| HFP 600P |
6 | 17,000 | 720 | 1,000 |
100 |
| HFP 1000P | 16,500 | 1,122 | 1,100 | ||
| HFP 1400P | 17,000 | 1,453 | 1,200 | ||
| HFP 600C |
6 | 16,500 | 720 | 1,000 |
100 |
| HFP 1000C | 16,000 | 1,122 | 1,100 | ||
| HFP 1400C | 16,000 | 1,453 | 1,200 | ||
| HFP 2700C | 15,200 | 2,753 | 1,600 |
103 | |
| HFP 4000C | 14,500 | 4,079 | 1,800 | ||
| HFP 6000C | 6,118 | 1,800 | |||
| HFP 4001C* | 6 | 10,200
| 4,079 | 1,800 | 90 |
Overall dimensions
| DRAWING | A | B | C | D | E | F | G | H | IN | WEIGHT |
| mm | mm | mm | mm | mm | mm | mm | mm | mm | kg | |
| A | 111 | 220 | 180 | 20 | 164 | 20 |
| 60 | 15 | 6.3 |
| 7.2 | ||||||||||
| 7.3 | ||||||||||
| B | 120 | 180 |
|
| 164 |
| 18 | 94 | 15 | 6.3 |
| 7.2 | ||||||||||
| 7.3 | ||||||||||
| C | 224 | 228 |
|
| 160 |
| 24 | 84 | 15 | 14 |
| 14.5 | ||||||||||
| 16.5 | ||||||||||
| 215 | 240 |
|
| 180 |
| 24 | 84 | 15 | 18 |
